Table 3-10 Combinations of Migration Methods Available in an PowerHA
Environment and the Migration Environments
Migration method
Migration environment
Host Virtual I/O server
Local boot disk
environment
Boot disk
environment
Local boot
disk
environment
#1
Boot disk
environment
installux.sh
#2
or
installp
command
Yes N/A No N/A
SMIT Yes N/A No N/A
Unattended
installation
No N/A No N/A
Installation on
alternate disks
No No No No
Installation in a
multibos
environment
No No No No
Legend:
Yes: Can be executed
No: Cannot be executed
N/A: Not applicable
#1
Before you migrate HDLM to an environment that uses PowerHA and a
virtual I/O server, cancel the virtual disk definitions of the virtual I/O
server. After you have migrated HDLM, redefine these virtual disk
definitions.
#2
Only new installations, upgrade installations, and re-installations are
supported.
For details about how to migrate, see each location shown below.
installux.sh
or installp command
Migrating from HDLM Version 5.8.1 or Earlier to Version 5.9 or Later on
page 3-61, and Migrating HDLM in a PowerHA 6.1 Environment on page
3-65 in Installing HDLM in a PowerHA 6.1 Environment on page 3-64.
To use SMIT, see the AIX documentation.
Creating an HDLM Environment
3-23
Hitachi Dynamic Link Manager (for AIX) User Guide
