Wireless Edge Services xl Module Release Notes WS.02.27
Table Of Contents
- Release Notes: Version WS.02.27 Software for the ProCurve Wireless Edge Services xl Module (J9001A) and the ProCurve Redundant Wireless Services xl Module (J9003A)
- Copyright and Disclaimers
- Contents
- Software Management
- Support Notes
- Release WS.02.07
- Reconfigure Management Passwords After a Software Update from Version WS.01.xx to Version WS.02.xx
- Accessing the Web Browser Interface After a Software Update from Version WS.01.xx to Version WS.02.xx
- Configuring Authentication for Web-Users
- Special Characters for the ACL ID Field
- Correction: SNMP v3 Default Password
- Correction: Stations per Radio
- Correction: Stations per Module in a Layer 3 Mobility Domain
- Correction: Disabling TKIP Countermeasures
- Clarification: Setting Intrusion Detection with TKIP Countermeasures
- Release WS.02.07
- Enhancements
- Software Fixes
- Known Software Issues and Limitations
- Back Cover
20
Enhancements
Release WS.02.07 Enhancements
Enhancements
With release WS.02.07 software, existing features have been enhanced. Redundancy groups can
include more members. Web authentication (Web-Auth) can be used with encryption. More digital
certificates are supported, and wireless traffic can be monitored more closely. Some features, are
configured in a slightly different way, such as Access Point detection and self-healing.
Capabilities and scalability of the ProCurve xl Wireless Edge Services Module have been improved.
The following table summarizes some of these improvements.
Table 3. Summary of Feature/Function Changes in WS.02.XX
Secure NTP Configure the module to take its time from an Network Time Protocol (NTP)
server, or act as a secure NTP server for other devices.
Web-Users accounts Create accounts for Web-Users, allow various levels of access to the
module’s Web browser interface.
ProCurve Identity Driven Manager (IDM) QoS Supports Quality of Service (QoS) settings created through IDM.
Feature/Function WS.01.XX WS.02.XX
Throughput - Unencrypted 290 mbits 400 mbits
Maximum number of Radio Ports supported 36 48
Maximum number of associated stations 1000 4096
Maximum number stations per radio 64 256
Maximum number of modules in Redundancy Group 2 12
Maximum number of VLANs per module 8 32
Radio Port Failover time (Layer 2) 55 sec typical 20 sec typical
Maximum number of static routes 1000 300
Maximum number RADIUS Authentications per second n/a 15 Internal / 5 LDAP
Maximum number of DHCP Lease Grants per second n/a 15
Maximum number of modules in Layer 3 Roaming Group n/a 12
Feature Description
