Configuring the ProCurve Wireless Edge Services xl Module
Management Interfaces
Accessing the Web Browser Interface for the Wireless Services-
Enabled Switch. You can also access the module’s Web browser interface
from the Web browser interface for the wireless services-enabled switch.
(Like the module’s Web browser interface, the switch’s Web browser interface
uses Java applets.) To access the switch’s Web browser interface, enter the IP
address for the management interface as the URL in your Web browser. For
example, if the management interface has the IP address 192.168.5.1, you
would enter http://192.168.5.1.
Like other modules installed in the wireless services-enabled switch, the
Wireless Edge Services xl Module is displayed on the switch graphic displayed
on the Device View screen. To access this screen, click Configuration > Device
View. (See Figure 2-1.)
Figure 2-1. The Web Browser Interface for the Wireless Services-Enabled Switch
To access the Web browser interface for the Wireless Edge Services xl Module,
click the link for the module, as shown in Figure 2-1.
Click the Link
for the Module
