2-14
Configuring the ProCurve Wireless Edge Services xl Module
Management Interfaces
Figure 2-4. Applying or Saving Changes
Logging Out or Refreshing the Screen
In addition to the Save link, the Web browser interface includes three links at
the top of the screen:
■ Refresh—updates the screen with current information
■ Support—links you to ProCurve Networking’s Web site at
http://www.procurve.com
■ Logoff—ends this management session
Note Refreshing the screen too often can cause the refresh to fail. Simply refresh
the browser again to rectify the problem.
Accessing the Online Help
Both information and configuration screens include a Help button, which
allows you to access the online help. (See Figure 2-5.)
Apply changes to
running-config
Access online
help
Remove
unapplied
changes
Save changes to
startup-config
