2-26

Configuring the ProCurve Wireless Edge Services xl Module

Management Interfaces

In addition, SNMP v3 secures communications between the user and the

managed device, transforming the traffic with an encryption algorithm, an

authentication algorithm, or both.

Default SNMP v3 Users—Manager and Operator.

There are two default

users:

■ Manager—The manager has read-write access, which means the man-

ager can configure settings and view information.

■ Operator—The operator has read-only access, which means the operator

can only view information. When a user accesses the Web browser inter-

face using the operator name and password, buttons (such as Apply or

Edit) that allow you to make configuration changes are unusable. (These

buttons are dimmed or missing from the screen, as shown in Figure 2-10.)

There is also an snmptrap user, which allows access to SNMP v3 traps sent by

the module.

Figure 2-10. Web Browser Interface (Operator Access)
