2-33

Configuring the ProCurve Wireless Edge Services xl Module

Management Interfaces

Figure 2-14. Setting Up the Internal FTP Server

3. In the Password box, enter a string, which can include alphanumeric and

special characters.

4. In the Root Dir field, specify the name of the directory with the files that

clients will request.

For example, enter flash:/.

If the file is stored in a directory within flash, the client must request the

file with the correct extension.

You can click the browse button to search for a different directory or to

create a new directory. See the steps below for more information on this

option.

5. Click the Apply button.

Browse

button
