Wireless/Redundant Edge Services xl Module Management and Configuration Guide WS.02.xx and greater

2-34
Configuring the ProCurve Wireless Edge Services xl Module
Management Interfaces
To use the browse button to select the root directory, follow these steps:
1. Click the browse button next to the Root Dir field. The Select Directory file
screen is displayed.
This screen displays three buttons, one for each of the Wireless Edge
Services xl Module’s three file systems:
•system:—stores the running-config
•nvram:—stores the startup-config
• flash:—stores a variety of files
2. Click one of the buttons at the top of the screen to choose the file system
in which the directory is located.
When you first open the screen, flash: is selected.
The section at the left of the screen lists directories within this file system.
For example, at factory settings, flash memory includes the four folders
shown in Figure 2-59.
Figure 2-15. Select Directory file Screen
3. In the left section, select the directory in which the Wireless Edge Services
xl Module searches for requested files.
Click the directory once to choose the directory. Its name is displayed in
the field at the bottom of the screen.
Flash file
system
Directories
