2-45

Configuring the ProCurve Wireless Edge Services xl Module

Management Interfaces

Configuring Authentication for Web-Users. Instead of (or in addition to)

using the local list to authenticate users, you can use a RADIUS server. If the

RADIUS server authenticates a user, that user has the rights configured on

the RADIUS database.

Note If you do not correctly configure the RADIUS server to send a user’s rights,

you can lock yourself out of the Wireless Edge Services xl Module Web

browser interface. Access the module CLI through the wireless services-

enabled switch. Enter this command to have the module authenticate Web-

Users against its local list:

Syntax: aaa authentication login default local

Then make sure that at least one user has been configured in the local list.

Follow these steps to choose how users authenticate when they attempt to

access the Wireless Edge Services xl Module’s Web browser interface:

1. Select Management > Web-Users.

2. Click the Authentication tab.
