2-74

Configuring the ProCurve Wireless Edge Services xl Module

Radio Port Adoption

8. If you selected an unadopted RP before clicking the Add button, the RP

MAC Address field displays the MAC address of that RP. Otherwise, enter

the RP’s Ethernet MAC address.

9. In the Radio Settings section, check the boxes for the radio types that you

want—802.11a or 802.11bg (or both).

10. For each radio type that you select, in the corresponding Radio Index field

enter a number to identify this RP.

11. Click the OK button.

You can also manually add a radio from the Network Setup > Radio screen.

Follow these steps:

1. Select Network Setup > Radio > Configuration.

Note that the screen informs you that automatic adoption is disabled. You

must manually add radios.

Figure 2-42. Network Setup > Radio Screen (Manual Adoption)

Manually

adopt a radio
