2-76

Configuring the ProCurve Wireless Edge Services xl Module

Radio Port Adoption

You set an RP’s ID by selecting one of its radios in the Network Setup > Radio

> Configuration screen and clicking the Edit button.

Figure 2-44. Radio Configuration Radio Settings

Then enter a value from 1 to 65535 in the Adoption Preference ID field. Match

the ID that you set for the Wireless Edge Services xl Module that should adopt

this RP.

Remember: RPs do not store their own radio configurations; they receive them

from a Wireless Edge Services xl Module. Therefore, you must create radio

configurations for each RP on each module, and you must set the correct

adoption preference IDs in these radio configurations. This allows the RP to

receive the correct ID no matter which module first detects its adoption

messages.

For example, if your system includes two modules and 30 RPs, you must create

the same radio configurations for all 30 RPs on both modules. And on both

modules, you would set some RP radios to the first module’s adoption prefer-

ence ID and some RP radios to the second module’s ID.

Set the adoption

preference ID to

match the module

that should adopt the

RP.
