2-77
Configuring the ProCurve Wireless Edge Services xl Module
Radio Port Adoption
You can create a radio configuration manually by clicking the Add button in
the Network Setup > Radio > Configuration screen and entering the RP’s Ethernet
MAC address. You can then edit the configuration and set the adoption
preference ID to match the module that should adopt that RP.
For a more efficient alternative, have one module pre-adopt all RPs and edit
the radio configurations on that module. Then copy those configurations to
other modules in the Wireless LAN System.
For more information on configuring adoption preference IDs, see “Setting up
Adoption Preference IDs to Control RP Adoption” on page 10-24 of
Chapter 10: Redundancy Groups. These instructions focus on the special
case of multiple Wireless Edge Services xl Modules and Redundant Wireless
Services xl Modules that form a redundancy group; however, they also apply
to modules that are not in a redundancy group but are part of the same Wireless
LAN System.
802.1X Authentication for RPs
To prevent rogue RPs from being adopted, you can also enforce 802.1X
authentication on your network switch ports. The ProCurve RPs 210, 220,
and 230 include an 802.1X client so that they can connect to ports that enforce
such authentication. Using MD5 authentication, the client automatically sends
the RP’s credentials when the RP connects to a network device. The switch
to which the RP connects forwards the credentials to an authentication server,
and if the credentials are correct, allows the RP to join the network.
The authentication server may store a VLAN setting for the RP, which it sends
to the switch after the RP authenticates. Such dynamic configuration of the
Radio Port VLAN can replace auto-provisioning on the wireless services-
enabled switch or manual configuration on an infrastructure switch. (See
“Communicating with RPs: Radio Port VLANs” on page 1-8 of Chapter 1:
Introduction for more information about configuring Radio Port VLANs.)
Note When you implement 802.1X on a port, auto-provisioning is disabled on that
port. You must either manually set the port to the correct VLAN for the RP or
configure the VLAN assignment on the RADIUS server.
However, the wireless services-enabled switch can continue to implement
auto provisioning on ports that do not enforce 802.1X.
