Wireless/Redundant Edge Services xl Module Management and Configuration Guide WS.02.xx and greater

2-94
Configuring the ProCurve Wireless Edge Services xl Module
System Maintenance
Managing the Directory Structure and Browsing for Files
The browse button appears when are choosing where to download files to the
Wireless Edge Services xl Module.
Figure 2-58. Browse Button
To use the browse button to search and manage the Wireless Edge Services
xl Module’s directory structure, follow these steps:
1. In the Target section, click the browse button next to the File field. The
Select Config file screen is displayed.
This screen displays three buttons, one for each of the Wireless Edge
Services xl Module’s three file systems:
•system:
•nvram:
• flash:
2. Click one of the buttons at the top of the screen to choose the file system
to which to save the file.
When you first open the screen, flash: is selected.
The section at the left of the screen lists directories, or folders, within this
file system. For example, at factory settings, flash memory includes the
four folders shown in Figure 2-59.
Browse
button
