2-95

Configuring the ProCurve Wireless Edge Services xl Module

System Maintenance

Figure 2-59. Select Config file Screen

The nvram stores the startup-config, and the system memory (volatile)

holds the running-config.

3. In the left section, choose the folder in which you want to save the file.

4. Alternatively, create a new folder (in the flash memory only).

a. Click the New Folder button. The New Folder screen is displayed.

Figure 2-60. New Folder Screen

b. Name the folder and click the OK button.

c. Your new folder is displayed in the left section of the Select Config file

screen. Select this folder.

Flash file

system

Subdirectories

(or folders)

Files saved

in this
