2-102
Configuring the ProCurve Wireless Edge Services xl Module
System Maintenance
Table 2-4. Image and Configuration Files Loaded When an Update Server Is
Defined
If the Wireless Edge Services xl Module cannot reach the Update Server, it
disables the Update Server settings. On the Management > System Maint.—
Update Server screen, the Update Server Unreachable box is checked. To enable
the Update Server once again, you must manually uncheck this box.
Image and Configuration
File on Module at Reboot
Image File Defined on
Update Server Screen and
Checksum of Startup-Config
Image and Configuration
File Stored on Update Server
Image and Configuration File
Used to Reboot Module
Image 1
Startup-config
Image 1
Startup-config
Does not matter
Does not matter
Image 1
Startup-config
Image 1
Startup-config
Not set
Startup-config
Does not matter
Does not matter
Image 1
Startup-config
Image 1
Corrupted startup-config
Image 1
Startup-config
Does not matter
Update Server is unavailable
or file location is incorrect
Image 1
Factory default startup-config
Image 1
Corrupted startup-config
Image 2
Startup-config
Update Server is unavailable
or file locations are incorrect
Image 1
Factory default startup-config
Image 1
Startup-config
Image 2
Startup-config
Update Server is unavailable
or file locations are incorrect
Image 1
Factory default startup-config
