2-107

Configuring the ProCurve Wireless Edge Services xl Module

System Maintenance

Figure 2-65. ConfigPasswdEn Button

2. Click the ConfigPasswdEn button.

Figure 2-66. ConfigPasswdEncryption Screen

Set the

encryption key

for passwords
