2-117
Configuring the ProCurve Wireless Edge Services xl Module
SNMP Traps and Error Reporting
Table 2-6. Wireless Statistics Thresholds
You can also configure the minimum number of packets required to send an
SNMP trap. By default, the minimum number of packets is 1,000.
Sending Traps to an SNMP Receiver
SNMP agents send only one type of unsolicited message: trap messages. SNMP
agents send trap messages to report events. These messages enable the SNMP
server to generate logs and alarms. You can configure SNMP trap receivers—
the SNMP servers to which the Wireless Edge Services xl Module sends trap
messages.
The module can send two types of traps:
■ v2c traps—always use public for the community name
■ v3 traps—use the snmptrap username and password (by default,
procurve) (see “Change the Password for SNMP v3 Traps” on page 2-119)
Define an SNMP Server. To define an SNMP server, complete these steps:
1. Select Management > SNMP Trap Receivers.
Thresholds Set for Station, Radio, WLAN, or
Module
Packets Per Second Station, radio, WLAN, or module
Throughput Station, radio, WLAN, or module
Average Bit Speed Station, radio, or WLAN
Average Station Signal Station, radio, or WLAN
Non-Unicast Packets Station, radio, or WLAN
Transmitted Packet Dropped Station, radio, or WLAN
Transmitted Packet Average Retries Station, radio, or WLAN
Undecrypt Received Packets Station, radio, or WLAN
Total Stations Radio, WLAN, or module
