2-123

Configuring the ProCurve Wireless Edge Services xl Module

Radio Port Licenses

Each Wireless Edge Services xl Module (J9001A) ships with 12 nonremovable

RP licenses. When you install the Wireless Edge Services xl Module into a

switch, the module can automatically adopt up to 12 RPs. If you move the

Wireless Edge Services xl Module to another switch, these 12 RP licenses

move with the module. They cannot be uninstalled or transferred to another

Wireless Edge Services xl Module.

If you want to manage more than 12 RPs through a Wireless Edge Services xl

Module, you can purchase and install a ProCurve Wireless Services Module

12 RP License (J9002A), which includes 12 additional RP licenses. You can

purchase up to three additional ProCurve Wireless Services Module 12 RP

Licenses for each Wireless Edge Services xl Module. As Table 2-7 shows, with

the additive licenses installed, each Wireless Edge Services xl Module can

adopt a maximum of 48 RPs.

Table 2-7. Radio Port Licensing per Wireless Edge Services xl Module

Because each radio port has a maximum of two radios, each Wireless Edge

Services xl Module can manage up to 96 radios.

Products Total Number of RP

Licenses

• Wireless Edge Services xl Module (J9001A) 12

• Wireless Edge Services xl Module (J9001A)

• Wireless Services Module 12 RP License (J9002A)

• Wireless Edge Services xl Module (J9001A)

• Wireless Services Module 12 RP License (J9002A)

• Wireless Edge Services xl Module (J9001A)

• Wireless Services Module 12 RP License (J9002A)
