3-3
Radio Port Configuration
Country-Code and Regulatory Procedures
tions on enabling the best possible roaming between RPs adopted by multiple
Wireless Edge Services xl Modules can be found in Chapter 9: Fast Layer 2
Roaming and Layer 3 Mobility.
In addition, the ProCurve RPs improve quality of service (QoS) in the wireless
network with support for Wi-Fi Multimedia (WMM). Each radio can divide
outbound wireless traffic into four queues based on priority value or on WLAN.
For example, voice traffic (if appropriately marked) is placed in the highest-
priority queue. The default settings for each queue are designed to provide a
high QoS for voice and video traffic from RPs to associated stations. The RPs’
QoS capabilities are discussed with the capabilities of the Wireless LAN
System as a whole in “Traffic Management (QoS)” on page 4-90 of Chapter 4:
Wireless Local Area Networks (WLANs).
Country-Code and Regulatory
Procedures
While IEEE has codified the international wireless network specifications and
standards, each country has its own regulations for legal frequencies and
wireless use requirements. It is important to be aware of your country’s
standards when configuring your network.
Setting a device’s country code configures it to use radio settings that are legal
in that country. You must set the country code on your ProCurve Wireless Edge
Services xl Module before it will adopt RPs. Complete these steps:
1. Select Network Setup and click the Configuration tab.
2. In the Country field, use the drop-down menu to select your country. (See
Figure 3-1.)
3. Click the Apply button.
