3-10

Radio Port Configuration

Configuring Radio Settings

Figure 3-5. Radio Adoption Default Configuration Properties

This screen includes three sections: Properties, Radio Settings, and Advanced

Properties. In the following sections, you will learn how to configure each of

the settings on this screen.

Viewing and Configuring Properties

For the most part, you view, rather than configure, settings in this section. The

Model field indicates that these radio settings apply to the 200 series ProCurve

RPs, and the Radio Type field indicates for which 802.11 mode you are config-

uring settings.

You can also define all radios of this mode as dedicated detectors.

Adopting Radios as Detectors. To increase network security, you can con-

figure a radio to constantly scan for neighboring access points (APs) not

connected to this Wireless Edge Services xl Module. Such a radio is called a

detector, and it cannot provide a connection for wireless stations.

Model

Radio Type

Dedicated to

detecting

rogue APs

Background AP

detection
