3-34

Radio Port Configuration

Configuring Radio Settings

However, a particular RP radio sends out beacons on each of its four BSSIDs,

and the Wireless Edge Services xl Module allows you to set a different DTIM

period for each BSSID. In this way, you can, for example, set a higher DTIM

period on a BSSID that supports a traditional data WLAN, but a lower DTIM

period on a BSSID that supports a voice WLAN.

To find the BSSID used by your WLAN (with normal configuration), see

Table 3-3. Advanced mode configuration allows you to change these assign-

ments. (See “Configuration Options: Normal Versus Advanced Mode” on page

4-4 of Chapter 4: Wireless Local Area Networks (WLANs).)

Table 3-3. WLAN Assignment to BSSID

To configure DTIM periods for a particular radio, complete these steps:

1. Select Network Setup > Radio > Configuration.

2. Select the radio that you want to configure and click the Edit button.

SSIDs for WLANs BSSID

1, 5, 9, 13 1

2, 6, 10, 14 2

3, 7, 11, 15 3

4, 8, 12, 16 4
