4-49
Wireless Local Area Networks (WLANs)
Configuring a WLAN
Table 4-2 displays the names that this management and configuration guide
uses for combinations of authentication and encryption options.
Table 4-2. Encryption and Authentication Options
Configuring Static WEP Encryption (No Authentication). If you
enable WEP encryption without authentication, WEP keys both encrypt wire-
less traffic and provide rudimentary authentication. You set the WEP key
manually; wireless users must enter the same key before they can connect to
the WLAN. This security option is sometimes called static WEP because you
set the key manually.
Authentication Encryption Called
None WEP (64-bit or 128-bit) Static WEP
WPA/WPA2 TKIP WPA/WPA2 with
preshared keys (PSK)
WPA2 AES WPA2-PSK
MAC authentication None RADIUS MAC
authentication
WEP (64-bit or 128-bit) RADIUS MAC
authentication and
static WEP
WPA/WPA2 TKIP RADIUS MAC
authentication and
WPA/WPA2-PSK
WPA2 AES RADIUS MAC
authentication and
WPA2-PSK
802.1X WEP (64-bit or 128-bit) Dynamic WEP
WPA/WPA2 TKIP WPA/WPA2 with 802.1X
WPA2 AES WPA2 with 802.1X (802.11i
standard)
Web-Auth None Web-Auth
WEP (64-bit or 128-bit) Web-Auth and
static WEP
WPA/WPA2 TKIP Web-Auth and
WPA/WPA2-PSK
WPA2 AES Web-Auth
