4-63

Wireless Local Area Networks (WLANs)

Configuring a WLAN

Table 4-6. Encryption Options for Web-Auth

Configuring Advanced WLAN Settings

In the Advanced section of a WLAN’s Edit screen, you can establish more

specialized settings for a WLAN.

This section will explain how to configure:

■ control over inter-station traffic

■ closed system operations

■ inactivity timeouts

You will learn how to configure other advanced settings, which deal with QoS

capabilities, in “Traffic Management (QoS)” on page 4-90.

Controlling Inter-Station Traffic

Often, a wireless network serves simply to connect mobile users to your

Ethernet network or to the Internet. In this case, wireless stations primarily

need to communicate with the Wireless Edge Services xl Module and servers

in the wired network; they do not need to communicate with other wireless

stations. However, by default they are allowed to do so (albeit through their

RPs since infrastructure mode requires that wireless stations send all traffic

to the RP).

Encryption Option Security Option Reference

WEP 64 static WEP “Configuring Static WEP

Encryption (No

Authentication)” on

page 4-49

WEP 128 static WEP “Configuring Static WEP

Encryption (No

Authentication)” on

page 4-49

WPA/WPA2-TKIP WPA/WPA2-PSK “Configuring WPA/WPA2-

PSK” on page 4-59

WPA2-AES WPA2-PSK “Configuring WPA/WPA2-

PSK” on page 4-59

WPA/WPA2-TKIP and

WPA2-AES

WPA/WPA2-PSK “Configuring WPA/WPA2-

PSK” on page 4-59
