4-74

Wireless Local Area Networks (WLANs)

Configuring a WLAN

Figure 4-43. Specifying the Accounting Server in the Radius Configuration Screen

To enforce RADIUS accounting, the WLAN must use 802.1X authentica-

tion, Web-Auth, or MAC authentication for the Authentication mode.

5. Configure settings for the primary accounting server in the Primary

column of the Accounting section.

a. Specify the server’s IP address in the Accounting Server Address field.

To use the Wireless Edge Services xl Module’s internal server for

accounting, enter 127.0.0.1.

b. Enter your RADIUS accounting server’s port in the Accounting Port

field.

Typically, leave the default port: 1813.

Accounting

settings
