4-97

Wireless Local Area Networks (WLANs)

Traffic Management (QoS)

Figure 4-55. Enabling WMM on a WLAN

2. Under Advanced, in the Access Category drop-down menu, select Auto-

matic/WMM.

3. Click the OK button.

The next section explains how to make some advanced configurations for

WMM.

Changing the Protocol that Prioritizes Traffic and Enabling

Admission Control

As discussed earlier, when you enable WMM, wireless devices queue frames

according to QoS marks. The default protocol for the QoS mark is 802.1p.

However, you can change the protocol to DSCP by accessing advanced WMM

parameters.

Enable WMM
