4-107

Wireless Local Area Networks (WLANs)

Traffic Management (QoS)

Table 4-9. Priority Values for WMM ACs

The mapping of priority value to AC occurs as traffic is prepared for transmis-

sion in a WLAN. For traffic traveling the opposite direction—from the WLAN

to the Ethernet—the Wireless Edge Services xl Module reverses the operation,

marking traffic that arrives in a particular AC with a priority value.

You can change the mapping to customize your network’s queues. Follow

these steps:

1. Select Network Setup > WLAN Setup and click the WMM tab.

2. Click the QoS Mappings button. The QoS Mappings screen is displayed.

Queue Number AC 802.1p Priority DSCP

1 Background 1, 2 8-23

2 Best effort 0, 3 0-7. 24-31

3 Video 4, 5 32-47

4 Voice 6, 7 48-63
