5-2

Web Authentication for Mobile Users

Overview

With the ProCurve Wireless Edge Services xl Module, you can require mobile

users to authenticate by entering their login credentials on a Web page. Like

other authentication methods, Web authentication (Web-Auth) is verified

through a Remote Access Dial In User Service (RADIUS) server.

You can use Web-Auth to provide limited network services for mobile users

who visit your company’s office. For example, you might want to provide

Internet access so that these users can browse the World Wide Web or

establish a virtual private network (VPN) to their company’s network.

Through the security provided over a VPN, users can access the applications

(such as email) and the data that they need to do their jobs.

In addition to using Web-Auth to provide network services for visitors, you

can use Web-Auth to provide authenticated access for employees who are

using stations that do not support 802.1X. Because Web-Auth is easy to

configure and provides an easy access method for users, you may also want

to use this authentication method for employees who need limited network

services.

Note

With Web-Auth, mobile users roam seamlessly between RPs adopted by the

same Wireless Edges Services xl Module. To have stations roam at Layer 2

between RPs adopted by different modules, you must place the modules in a

redundancy group. (See

Chapter 10: Redundancy Groups

.) To have stations

roam between modules at Layer 3, you must place the modules in a Layer 3

mobility domain. (See

Chapter 9: Fast Layer 2 Roaming and Layer 3

Mobility

However, the redundancy group, like the module, is limited to adopting 48

RPs. Consider having a single module adopt all RPs. (You can install RPs in

a different subnetwork than the Wireless Edge Services xl Module that adopts

them. See “Network Requirements for Layer 3 Adoption” on page 2-61 of

Chapter 2: Configuring the ProCurve Wireless Edge Services xl Module
