5-18
Web Authentication for Mobile Users
Configuring Web-Auth
Figure 5-11. Displaying the Main Logo on the Web-Auth Login Page
4. Configure the welcome page, which mobile users see if they enter a valid
username and password and the RADIUS server authenticates them.
a. Click the Welcome tab. (See Figure 5-12.)
Descriptive text
The main logo is
displayed at the
top of the page
Footer text
Header text
