5-19

Web Authentication for Mobile Users

Configuring Web-Auth

Figure 5-12. Configuring the Welcome Page

b. In the Title Text field, accept the default text shown on the screen, or

enter the text that you want to use.

c. In the Header Text field, accept the default text shown on the screen,

or enter the text that you want users to see when they log in. (See

Figure 5-13.)

Note If you customize the Header Text, Footer Text, or Descriptive Text fields, you can

enter a maximum of 1,024 characters.

d. In the Footer Text field, enter the text that will be displayed at the

bottom of the welcome page. By default, this field is empty.
