5-20
Web Authentication for Mobile Users
Configuring Web-Auth
e. In the Small Logo URL field, enter the name of a logo file to include a
small logo on the welcome page. (See Figure 5-13.) You must copy
this logo to the flash on the Wireless Edge Services xl Module. (For
instructions on how to copy the logo file to flash, see “Copying Logo
Files to the Module’s Flash” on page 5-32.)
Figure 5-13. Displaying a Small Logo on the Web-Auth Welcome Page
f. In the Main Logo URL field, enter the name of a logo file to display a
logo at the top of the welcome page. (See Figure 5-14.) You must copy
this logo to the flash on the Wireless Edge Services xl Module. (For
instructions on how to copy the logo file to flash, see “Copying Logo
Files to the Module’s Flash” on page 5-32.)
g. In the Descriptive Text field, accept the default text shown on the
screen, or customize the text as needed. (See Figure 5-14.)
Descriptive text
The small logo is
displayed at the
bottom of the page
Header
text
Disconnect link
Duration of the
connection
