5-21
Web Authentication for Mobile Users
Configuring Web-Auth
Figure 5-14. Displaying the Main Logo on the Web-Auth Welcome Page
5. Configure the failed page, which mobile users see if they enter an invalid
username and password.
a. Click the Failed tab. (See Figure 5-15.)
Descriptive text
The main logo is
displayed at the
top of the page
Header text
Disconnect link
Duration of the
connection
