5-23
Web Authentication for Mobile Users
Configuring Web-Auth
e. In the
Small Logo URL
field, enter the name of a logo file to include a small
logo on the failed page. (See Figure 5-16.) You must copy this logo to
the module’s flash. (For instructions on how to copy the logo file to flash,
see “Copying Logo Files to the Module’s Flash” on page 5-32.)
Figure 5-16. Displaying the Small Logo on the Web-Auth Failed Page
f. In the Main Logo URL field, enter the name of a logo file to include a
large logo on the failed page. (See Figure 5-17.) You must copy this
logo to the flash on the Wireless Edge Services xl Module. (For
instructions on how to copy the logo file to flash, see “Copying Logo
Files to the Module’s Flash” on page 5-32.)
g. In the Descriptive Text field, accept the default text shown on the
screen, or customize the text as needed. (See Figure 5-17.)
Header
text
Descriptive text
The small logo is
displayed above
the footer
Footer text
Link to the
login page
