6-15

IP Services—IP Settings, DHCP, and DNS

IP Routing

6. Click the OK button to apply the change to the running-config.

7. Click the Save link at the top of the Web browser interface to save the

changes to the startup-config.

Specifying a Default Route and Gateway

A default route is a special static route that applies to all traffic for which the

Wireless Edge Services xl Module does not know another route.

When you use the CLI to configure the Wireless Edge Services xl Module’s

default gateway, the module automatically creates a default route to that

gateway. This route is listed in the Network Setup > Internet Protocol > IP

Forwarding screen. (See Figure 6-10.)

Figure 6-10. Viewing the Default Route

Default route

Default gateway
