IP Services—IP Settings, DHCP, and DNS
IP Routing
Although you can add another default route manually (or, from the CLI, specify
another default gateway), only one default route is active—the first route
configured. To avoid confusion, ProCurve Networking recommends that you
delete all but one default route.
Figure 6-11. Multiple Default Routes
Follow these steps to configure or to change the Wireless Edge Services xl
Module’s default route:
1. Select Network Setup > Internet Protocol and click the IP Forwarding tab.
2. If the route table already lists a default route, select that route and click
the Delete button.
3. Click the Add button at the bottom of the screen. The Add static route
screen is displayed.
4. In the Destination Subnet field, enter 0.0.0.0.
5. In the Subnet Mask field, enter 0.0.0.0.
6. In the Gateway Address field, enter the IP address of the new default
gateway.
This route has
no effect unless
you delete the
first route
Two default routes
