7-14
Access Control Lists (ACLs)
Configuring ACLs
Creating Rules for Standard IP ACLs
The standard IP ACL offers a variety of options for rules. However, some of
these options only take effect on certain interfaces. As you create the rule,
keep in mind the interface for which you are designing this ACL. In Table 7-3,
an X under the interface means that the option is supported for that interface.
Table 7-3. Valid Options for Standard IP ACLs Depending on Interface
To create a rule for a standard IP ACL, complete these steps:
1. On the Security > ACLs > Configuration screen, in the ACLs section, select
a standard IP ACL.
2. Click the Add button under Associated Rules. The Add Rule screen is
displayed.
Option VLAN/Tunnel
Interface
Uplink Port Downlink Port
deny operation X X X
permit operation X X X
mark operation X X
source IP address
and mask
XXX
WLAN index X
