7-30
Access Control Lists (ACLs)
Configuring ACLs
Table 7-7. Protocol IDs for ACL Statistics
■ Low Source IP—the lowest source IP address specified for the rule
■ High Source IP—the highest source IP address specified for the rule
■ Low Destination IP—the lowest destination IP address specified for the rule
(always 0.0.0.0 for standard ACLs)
■ High Destination IP—the highest destination IP address specified for the
rule (always 0.0.0.0 for standard ACLs)
■ Times Used—the number of times that the Wireless Edge Services xl
Module has applied the ACL rule to traffic
The counter increments when the module drops a denied packet or when
permits the first packet in a session. The Wireless Edge Services xl Module
support stateful ACLs, which means that it automatically allows all traffic
in the session.
Check this column periodically to ensure that ACL rules are affecting
traffic. If not, you might need to reconfigure ACLs to make them more
relevant to your network. You can also check for a deny rule that filters
out traffic that should be allowed.
To view detailed statistics for a specific interface, select the interface and click
the Details button. The Details screen is displayed.
ID Protocol
-1 IP
1ICMP
6TCP
17 UDP
