Configuring Network Address Translation (NAT)
Overview
Table 8-2 summarizes this terminology.
Table 8-2. Terminology for IP Addresses According to NAT Implementation
NAT Interface Type
(Inside or Outside)
NAT Address
Type
Address Explanation of Address
Inside Source Local An inside station’s IP address as it appears on the inside
network
Inside Source Global An inside station’s IP address as it appears on the outside
network
Inside Destination Local An outside station’s IP address as it appears on the inside
network
Inside Destination Global An outside station’s IP address as it appears on the outside
network
Outside Source Local An outside station’s IP address as it appears on the outside
network
Outside Source Global An outside station’s IP address as it appears on the inside
network
Outside Destination Local An inside station’s IP address as it appears on the outside
network
Outside Destination Global An inside station’s IP address as it appears on the inside
network
