Configuring Network Address Translation (NAT)
Planning the NAT Configuration
When you record the global address for destination NAT, identify the inside
device’s IP address as it appears in the destination network. For the sample
network, the Web server’s actual IP address is 192.168.1.25. You would,
therefore, record 192.168.1.25 as the global address.
Because the sample network is also using port address translation, you should
record the port for the translated traffic, as shown in Table 8-4.
Table 8-4. Recording Addresses for Outside Destination NAT
NAT
Interface
Ty pe
NAT Address
Type
Local or Global Address Local or Global Port Recorded
Addresses for the
Sample Network
Recorded Ports
for the Sample
Network
Inside Destination Local (outside device’s IP
address as it appears on
the inside network)
Local (port to which the
inside devices originally
send traffic)
10.1.1.1 80
Inside Destination Global (outside device’s IP
address as it appears on
the outside network)
Global (port used by the
outside device)
192.168.1.25 51000
