8-30

Configuring Network Address Translation (NAT)

Configuring NAT

Table 8-5. Determining the IP Address for the Local Address Field

For example, for source NAT, enter the configured IP address

assigned to a device in its own network. This address is typically

allocated out of a private address space.

b. The Local Port field is not available for source NAT.

5. In the After Translation section, specify the IP address to which the Wireless

Edge Services xl Module should translate the source address:

a. In the Global Address field, enter the IP address as it should appear

after translation.

See Table 8-6 for guidelines on specifying this address.

Table 8-6. Determining the IP Address for the Global Address Field

Make sure to enter a valid IP address on this Wireless Edge Services

xl Module. Select an address that is valid in the network to which the

traffic is destined. For example, if you are configuring source NAT for

a wireless device, enter an IP address on a VLAN tagged on the uplink.

b. The Global Port field is not available for source NAT. The Wireless Edge

Services xl Module automatically assigns a port to the translated

packet.

6. Click the OK button.

The static NAT definition is now listed on the Security > NAT > Static Translation

screen. Remember: the translation does not take effect unless you define an

interface as the type on which you configured static source NAT. (See “Defin-

ing Interfaces as Outside or Inside” on page 8-22.)

Interface Type Address Type IP Address for the Local Address Field

Inside (Private) Source IP address of an inside device as it appears on the

inside network

Outside (Public) Source IP address of an outside device as it appears on the

outside network

Interface Type Address Type IP Address for the Global Address Field

Inside (Private) Source IP address of an inside device as it should appear

on the outside network

Outside (Public) Source IP address of an outside device as it should

appear on the inside network
