9-14

Fast Layer 2 Roaming and Layer 3 Mobility

Configuring Layer 3 Mobility

You must complete these tasks to configure Layer 3 mobility:

1. Configure Layer 3 mobility settings for the local Wireless Edge Services

xl Module:

• IP address

• WLANs on which Layer 3 mobility is enabled

2. Specify the peers’ IP addresses.

3. Enable Layer 3 mobility.

4. Save the configuration and complete these steps on all other Wireless

Edge Services xl Modules in the Layer 3 mobility domain.

It is assumed that you have completed the configurations outlined in Table 9-2.

Note You cannot use user-based, or dynamic, VLANs in a WLAN assigned to the

Layer 3 mobility domain. In other words, the Dynamic Assignment box in the

WLAN’s Edit screen must be unchecked.

Table 9-2. Other Configurations Necessary for Layer 3 Roaming

Configuration Necessary Settings

WLAN configuration (for each WLAN

on which Layer 3 mobility is enabled)

• SSID and security settings are the same as peers’

settings.

• VLAN ID is different from at least some peers’

VLAN settings. (Different subnetworks

must have

different VLAN IDs.)

• Dynamic VLAN assignment is disabled.

IP configuration on the local module • The module can reach peers.

• The peers can reach the module.

IP configuration for stations • DHCP is provided through either:

– local DHCP pool for the VLAN mapped to the

WLAN

– external DHCP server

• Static IP addresses, if used, are manually

configured (not typical).
