11-7

RADIUS Server

RADIUS Authentication

Figure 11-2. Choosing the EAP Method

2. From the 802.1x EAP/Auth Type drop-down menu, select a method. Select

all to allow users to authenticate with any of the supported methods.

3. Next, choose your server’s digital certificates (explained in the section

below). Or click the Apply button and, when the screen is displayed asking

you to restart the server, click the Yes button.

Choose the EAP

method for 802.1X

authentication
