11-10

RADIUS Server

RADIUS Authentication

Figure 11-3. Choosing the Source for Credentials

2. In the Auth Data Source field, use the drop-down menu to select the source

for policies and credentials, either local or ldap.

3. Click the Apply button and, when the screen is displayed asking you to

restart the server, click the Yes button.

4. Click the Save link to copy the configuration to the startup-config.

Choose the

location for user

credentials
