Wireless/Redundant Edge Services xl Module Management and Configuration Guide WS.02.xx and greater

11-38
RADIUS Server
RADIUS Accounting
Enabling Accounting to the Internal RADIUS Server on
a WLAN
To activate accounting to the internal RADIUS server, follow these steps:
1. Select Network Setup > WLAN Setup > Configuration.
2. Select the WLAN from the list and click the Edit button. The Edit screen
for the WLAN is displayed.
Acct-Output-Packets • number of packets sent by the station over the entire
duration of the session (stop message)
• number of packets sent by the station since the beginning
of the session (interim message)
Acct-Input-Octets • number of bytes received by the station over the entire
duration of the session (stop message)
• number of bytes received by the station since the
beginning of the session (interim message)
Acct-Output-Octets • number of bytes sent by the station over the entire duration
of the session (stop message)
• number of bytes sent by the station since the beginning of
the session (interim message)
Acct-Terminate-Cause the reason that the station’s session ended (stop messages
only)—for example, the user might log off (User-Request) or
the session might time out due to inactivity
Field Meaning
