Wireless/Redundant Edge Services xl Module Management and Configuration Guide WS.02.xx and greater

1-51
Introduction
ProCurve Wireless Edge Services xl Module
Table 1-4. RP Licenses and the Number of RPs Supported
You install additive licenses on a particular module, and only that module can
adopt the additional RPs. However, you can uninstall additive licenses and
then install them on a different module.
For example, suppose you install an additive license on a Wireless Edge
Services xl Module so that it can adopt 24 RPs. Later, you decide that a
different module should support additional RPs. You uninstall the additive
license from the first module and install it on the second. In other words, if
you need to move RPs within your network, you can move RP licenses instead
of moving an entire module.
Note You can move only additive licenses. You can never remove a module’s
original license for 12 RPs and install it on another module.
Products Maximum Number
of RPs
Maximum Number
of Radios
Wireless Edge Services xl Module (J9001A) 12 24
Wireless Edge Services xl Module (J9001A)
Wireless Services Module 12 RP License
(J9002A)
24 48
Wireless Edge Services xl Module (J9001A)
2 Wireless Services Module 12 RP Licenses
(J9002A)
36 72
Wireless Edge Services xl Module (J9001A)
3 Wireless Services Module 12 RP Licenses
(J9002A)
48 96
