13-26

Wireless Network Management

Monitoring the Wireless Network

WLAN Statistics

To monitor wireless activity on a WLAN-wide scale, select Network Setup >

WLAN Setup and click the Statistics tab.

Figure 13-16.Network Setup > WLAN Setup > Statistics Screen

This screen lists every WLAN that is enabled on the module. WLANs are

identified by:

■ Index (the WLAN’s number)

■ SSID

■ Description

■ VLAN

The Stations column shows the number of stations currently connected to that

WLAN.

The remaining columns display statistics similar to those described in “Wire-

less Statistics for Stations” on page 13-12; however, these statistics are aver-

ages for all stations in the WLAN:

Module Statistics

button
