13-62

Wireless Network Management

Logging and Alarms

The Wireless Edge Services xl Module generates logs for various events that

occur on a system; these logs report on messages that the module receives

and actions that the module takes. The module can log events to:

■ its buffer

■ the console

■ an external server

Events are ranked according to severity, as shown in Table 13-2. The lower the

number, the greater the risk to network functionality.

Table 13-2. Event Severity

The Wireless Edge Services xl Module can also log alarms, which it receives

when an SNMP trap is triggered. These alarms are stored in the module’s local

alarm log; the module can also forward alarms to an external server.

Level Severity

0 Emergency

1Alert

2Critical

3 Error

4 Warning

5Notice

6Info

7 Debugs
