13-84

Wireless Network Management

MAC Filters (Local MAC Authentication)

To import MAC standard ACLs to your Wireless Edge Services xl Module,

follow these steps:

1. Select Security > MAC Filters.

2. Click the Import button.

Figure 13-60.Importing ACLs

3. A dialog screen is displayed for choosing the file from the local disk of

your management station. Find your file and confirm the import.

4. A screen reports the results of the import. If the import is completely

successful, the message shown in Figure 13-61 is displayed.

If you see any errors, refer to “Resolving Import Errors” on page 13-85.

Import button
