13-99

Wireless Network Management

Network Self Healing

The Wireless Edge Services xl Module subtracts the offset from the maximum

power allowed in your regulatory domain to define the maximum power for

that radio. To configure this parameter, complete these steps:

1. Select Network Setup > Radio > Configuration.

2. Select the radio and click the Edit button. The Configuration screen for the

selected radio is displayed. (See Figure 13-71.)

Figure 13-71.Configuring the Self Healing Offset Option

3. In the Advanced Properties section, enter a value in the Self Healing Offset

field.

Base the offset on the radio’s antenna gain and the rules of your regulatory

domain as explained in http://www.hp.com/rnd/support/manuals/

rports.htm.

4. Click the OK button.

Self Healing

Offset
