A-9

ProCurve Wireless Services xl Module Command Line Reference

Manager Commands

acknowledge

This command acknowledges the presence of alarms.

Syntax

acknowledge alarm-log (all | <1-65535>)

• alarm-log - Acknowledge the alarm logs.

– all - Acknowledge all alarms.

– <1-65535> - Acknowledge specific alarm ID

Default Setting

N/A

Command Mode

Manager

Example

This command changes the current directory.

Syntax

cd (DIR | )

• DIR - Change current directory to DIR.

Default Setting

N/A

Command Mode

Manager

Example

ProCurve(wireless-services-B)#acknowledge alarm-log 65535

ProCurve(wireless-services-B)#

ProCurve(wireless-services-B)#cd

ProCurve(wireless-services-B)#

ProCurve(wireless-services-B)#cd TESTDIR

ProCurve(wireless-services-B)#
