A-12

ProCurve Wireless Services xl Module Command Line Reference

Manager Commands

Default Setting

N/A

Command Mode

Manager Exec

Example

debug cc

This command traces cellcontroller (wireless) debugging messages. The no

command negates the trace.

Syntax

debug cc (err | warn | info | all)

• err- Trace error messages from the cellcontroller. The no version of the

command negates the trace.

• warn- Trace error and warning messages from the cellcontroller. The no

version of the command negates the trace.

• info - Trace error, warning, and informational messages from the cellcon-

troller. The no version of the command negates the trace.

• all - Trace all messages from the cellcontroller. The no version of the

command negates the trace.

Default Setting

N/A

Command Mode

Manager Exec

Example

ProCurve(wireless-services-B)#debug all

ProCurve(wireless-services-B)#

ProCurve(wireless-services-B)#debug cc err

ProCurve(wireless-services-B)#
