A-15

ProCurve Wireless Services xl Module Command Line Reference

Manager Commands

Example

debug nsm

This command traces network service module (NSM). The no command negates the

trace.

Syntax

debug nsm (all | events | kernel | packet)

• all- Trace all messages from the network service module. The no version of

the command negates the trace.

• events- Trace events messages from the network service module. The no

version of the command negates the trace.

• kernel - Trace kernel messages from the network service module.

• packet (recv | send|) (detail |)- Trace packet messages from the network

service module. The no version of the command negates the trace.

– detail - Detailed information display.

– recv - NSM receive packets.

+ detail - Detailed receive packet information display.

– send - NSM send packets.

+ detail - Detailed send packet information display.

Default Setting

N/A

Command Mode

Manager

Example

ProCurve(wireless-services-B)#debug mgmt cgi

ProCurve(wireless-services-B)#

ProCurve(wireless-services-B)#no debug mgmt sys

ProCurve(wireless-services-B)#

ProCurve(wireless-services-B)#debug nsm packet recv

ProCurve(wireless-services-B)#
